Passport  Duo 400W  Dual AC/DC Touch Charger

Passport Duo 400W Dual AC/DC Touch Charger

Part Number: DYNC3005

MSRP: $299.99
Available for*: $249.99

Find a Retailer
or
Buy Now
*At participating retailers

Overview

The Dynamite® Passport™ Duo 400W Dual AC/DC Touch Charger builds on the success of the the previous non-touch version and adds an intuitive easy to use touch screen interface and HV charging capabilities.

Features

  • Intuitive Touch Screen Display
  • HV (High Voltage) charging / discharging / balancing
  • Charges Li-Po/Li-Fe/ (1–6 cell), Ni-MH (1–15 cell) and Pb battery types
  • 500W internal power supply
  • 0.1–10.0A Adjustable charge current per output
  • Space saving dual output design
  • 200W charge power per output
  • 100-240 VAC (50/60Hz) or 11-18V DC input voltage
  • 25W discharge power per output
  • Detachable AC power cord / Optional DC power cord
  • Includes 2 EC3 charge connector and a variety of other connectors included
  • Short circuit protection
  • Over temperature protection / Over current protection
  • Low input voltage protection

Product Specifications

Type:Dual Battery Charger

Input:100-240V AC or 11-18V DC

Peak:Yes

Current Discharge:Adjustable

Charge Rate:Adjustable

Input Connector:AC cord, detachable, North American plug

Output Connector:Banana to EC3, Banana to Deans Compatible, Banana to Rx

Battery Type:Li-Ion/LiPo/LiFe/NiCd/NiMH/Pb

Cooling Method:Fan

Voltmeter:Yes

Amp Meter:Yes

LCD:Monochrome Touch Screen, 400x240

Overload Protection:Yes
